An outstanding cinematic experience

The VPL-HW65ES is a fantastic option for movie lovers who want an incredible cinematic experience at home, far beyond the reach of TV. It's packed with our latest technology, including Reality Creation and advanced SXRD panels for an incredibly sharp, crystal clear picture.

High brightness and contrast ratio
With 1800 lumens colour brightness and a contrast ratio of 120,000:1, you can enjoy your favourite films at their best, in 3D or 2D. Bright Cinema and Bright TV modes also ensure optimum brightness and superb, rich colour quality.

• Reality Creation - Super Resolution function

  Developed for our leading 4K home cinema projector (VPL-VW1000ES), Reality Creation reproduces colours and textures that are lost when movies are packaged to disc. It gives you crisper, sharper Full HD pictures, much closer to the 1080p original.

• 1,800 lumens brightness with faithful colour reproduction

  Thanks to an improved optical engine, the VPL-HW65ES is much brighter than our previous standard home cinema projectors. At 1,800 lumens, it produces clearer images and faithful colours, even in well-lit rooms.

• Bright Cinema and Bright TV modes

  Conventional home cinema projectors sacrifice some colour accuracy by increasing greens to improve brightness. With Bright Cinema and Bright TV modes, the VPL-HW65ES retains true colour and contrast, even in a bright environment.

• Dynamic contrast now 120,000:1

  Optical engine improvements and advanced Iris 3 technology mean we've achieved an incredible dynamic contrast ratio of 120,000:1. It maximises blacks and whites without diminishing brightness so you won't miss a detail, even in dark scenes.

• Long lasting lamp

  You can expect a longer lamp replacement time from the VPL-HW65ES: up to 6,000 hours (roughly 60% longer than our standard home cinema projectors). This lowers your running costs and total cost of ownership.

• Contrast Enhancer and advanced Iris3

  Automatically adjusts contrast for optimum viewing by analyzing dark and light areas in every scene, without diminishing colour.

• Motionflow

  See every detail, even in fast-moving action scenes or sports. Motionflow technology shows twice as many pictures per second by creating extra images between the original frames. The result is smoother, sharper motion with less blur.

• SXRD panel technology

  Our SXRD panels reduce pixel gaps and reproduce up to 240 frames per seconds for super-sharp images. Because our 3D glasses have a synchronised shutter speed, you'll enjoy incredible high-definition 3D with minimal crosstalk.

• Dynamic Lamp Control

  When each of the shutters of your 3D glasses opens, Dynamic Lamp Control boosts the brightness by three times: this maximises picture impact as well as lamp efficiency.

• Built-in IR 3D transmitter

  No set-up time or cables, just synchronise the VPL-HW65ES with your IR 3D glasses via the built-in transmitter. 3D Glasses available for purchase separately.

• 2D and 3D modes

  The VPL-HW55ES automatically recognises 2D or 3D content and allows you to pre-select Standard, Dynamic, Cinema, Game and Photo modes.

• Extremely low fan noise

  Our advanced cooling system means fan noise is reduced to a whisper-quiet 21db.

• Gamma adjustment

  Fine tune image brightness according to the light in the room or the on-screen picture. There are 11 modes to select from.

• Wider lens shift range

  A wider vertical range than our standard home cinema projectors allows more options for placement and installation, without reducing image quality.

• Perfect panel alignment

  Electronic panel alignment ensures precise colour and clarity. Any colour gaps are corrected by shifting the blue and red areas of each pixel into perfect alignment with green.

• Real Colour Processing (RCP Version 2)

  Adjust the colour and hue using a target on the projected picture. RCP Version 2 also allows you to adjust brightness at the same time.

Technical Specifications

General

Display system	High Frame Rate SXRD panel
Light Output	1800 lm
Contrast ratio	120,000:1 (Dynamic Contrast)
Display elements - Effective display size	0.61" x 3
Display elements - Effective pixels	Full HD(1920x1080)x3 6,220,800 pixels
Projection lens - Zoom / Focus	Manual (Approx. 1.6 x) / Manual
Projection lens - Lens shift	Manual, V:+/-71% / H:+/-25%
Light source	Ultra High-pressure lamp 200W type
Screen size	40" to 300''
Reality Creation	YES ( FullHD Reality Creation )
Compatible with 4K mastered Blu-ray	No
4K 60P (YUV420/8bit:YCbCr4:2:0/8 bit)	No
3D capability	YES
3D emitter	Built-in IR emitter ( Compatible with RF external emitter )
3D glasses	TDG-PJ1 ( IR type : Optional ) / TDG-BT500A (RF type : Optional)
Auto Calibration	No
Manual Calibration	RCP
Picture Position Memory	No
Wireless HDMI compatibility	IFU-WH1 ( Optional )
Advanced Iris	Ver 3
Picture modes	9 modes
Gamma modes	11 modes
Panel Alignment	Yes (Shift / Zone)
Input/Output - HDMI (2 inputs)	Digital RGB/Y Pb/Cb Pr/Cr
Input/Output - Y Pb/Cb Pr/Cr	Component: phono type
Input/Output - INPUT A	Mini D-sub 15-pin (RGB)
Input/Output - Remote	RS-232C, D-sub 9-pin (female)
Input/Output - IR IN	Mini Jack
Input/Output - 3D Sync	Built-in IR Transmitter or via RJ-45 ( External IR transmitter TMR-PJ2 or RF transmitter )
Acoustic noise*	21dB
Power requirement	AC 100 V to 240 V, 3.0 A to 1.3 A,50/60 Hz
Power consumption	Max. 300 W
Power Consumption (Standby Mode) - AC 100 V to 120 V	0.4W (when "Standby mode" is set to "Low")
Power Consumption (Standby Mode) - AC 220 V to 240 V	0.4W (when "Standby mode" is set to "Low")
Power Consumption (Networked Standby Mode) - AC 100 V to 120 V	6.0 W (HDMI) (when "Standby Mode" is set to "Standard")
Power Consumption (Networked Standby Mode) - AC 220 V to 240 V	6.0 W (HDMI) (when "Standby Mode" is set to "Standard")
Standby Mode/Network Standby Mode Activated	After about 10 minutes
Body Color	Black / White
Standard outside dimensions	W 407.4 x H 179.2 x D 463.9 mm
Weight	Approx. 9.6 kg
Supplied Accessories	Handheld Remote Control Size AA (R6) manganese batteries (2) AC Power Cord for projector (1) Operating Instructions(1)
