Anthem MRX-520 Home Theatre Receiver - Discontinued No Longer Available
Separates-Quality Performance in a Gutsy, Feature-Rich AV Receiver. (More information)
- Availability:
- Discontinued
- Categories:
- Home Cinema
- Sub-categories:
- AV Receivers
- Brand:
- Anthem
- Delivery:
- FREE Delivery Australia Wide
Need Affordable Installation?
For our Adelaide customers, Vision Hifi offers a range of affordable installation services for your home or office. Discover our Installation Services .
Buy this Product
Your Price
$2,299
(each)
FREE Delivery Australia Wide
This product is currently unavailable to order.
Related Products (View more related products)
-
Marantz CINEMA30: 11.4 Channel Premium AV Receiver
Built upon decades of rich heritage, designed with timeless style, and engineered for utmost performance, Marantz CINEMA Series are the foundation of the world's most demanding home theaters.$7,900 -
Denon: AVC-X85000HA - 13.2 Channel AV Controller
The Denon Flagship AVC-X8500HA powers the next generation of home theatre with the world’s first 13.2 channel AV Amplifier that supports the latest immersive audio formats, including Dolby Atmos, DTS:X and Auro-3D.$6,990(per each) -
SALE ENDS 2nd Dec at 5:00pm
Yamaha RX-A8A Aventage Home Theatre AV Receiver
The A8A is our most innovative model yet. This AV receiver incorporates cutting-edge components and technology for home cinema unlike anything you’ve ever experienced.$5,159(per each)Was $5,999Save $840. -
SALE ENDS 2nd Dec at 10:59am
Denon: AVC-X4800 - 9.4 Channel Home Theatre Receiver
Designed and manufactured in Japan, the powerful AVR-X4800H drives 9.4 channels of amplification. With Dolby Atmos and DTS:X, plus IMAX Enhanced and Auro 3D, the AVC-X4800H envelops larger living spaces in breathtaking 3D audio. With HEOS Built-in, wirelessly... read more$3,199(per each)Was $3,999Save $800.
Product Categories
Product Details
Experience the breathtaking power and multi-channel flexibility of Anthem's NEW Third Generation MRX Series of AV Receivers.
Anthem's award-winning Third Generation MRX Series of high-end multi-channel A/V receivers are known the world over for their excellent sound quality, efficient power handling, and the ease with which they integrate into an entertainment system. The MRX Series is packed with exclusive audio innovations like Anthem Room Correction (ARC) Technology and Advanced Load Monitoring (ALM) Technology, 4K Pass-Through with fast HDMI switching and more.
Specifications
| PREAMPLIFIER | ||
| Maximum Output (<0.1% THD) | 4.2 Vrms, subwoofer channel 5.2 Vrms | |
| Frequency Response (2 Vrms output) | 10 Hz ? 31 kHz (+0, -0.25 dB) | |
| Frequency Response, Analog-Direct (2 Vrms output) | 10 Hz ? 48 kHz (+0, -0.25 dB) | |
| THD+N (2 Vrms output) | -95 dB | |
| S/N Ratio (2 Vrms output, IEC-A filter) | 110 dB | |
| PREAMPLIFIER + AMPLIFIER (1 W OUTPUT) | ||
| MRX 1120 / MRX 720 | -88 dB channels 1-5, -75 db back/height | |
| MRX 520 | -88 dB | |
| MAXIMUM CONTINUOUS OUTPUT (1% THD) | |||
| MRX 1120 | MRX 720 | MRX 520 | |
|---|---|---|---|
| Channels 1-5, Two Driven into 8 Ohms | 140 W | 140 W | 100 W |
| Channels 1-5, Two Driven into 6 Ohms | 170 W | 170 W | 130 W |
| Remaining Channels, Two Driven into 8 Ohms | 60 W | 60 W | n/a |
| Remaining Channels, Two Driven into 6 Ohms | 75 W | 75 W | n/a |
| POWER CONSUMPTION | |||
| MRX 1120 | MRX 720 | MRX 520 | |
|---|---|---|---|
| Typical Load | 570 W | 485 W | 365 W |
| Standby | 0.3 W | 0.3 W | 0.3 W |
| Standby IP Control Enabled | 4.7 W | 4.7 W | 2.4 W |
| Standby HDMI Bypass Enabled | 8.2 W | 8.2 W | 5.8 W |
| DIMENSIONS | ||
| Height | 6-1/2" (16.5 cm) | |
| Height with Rackmount Kit | 4U | |
| Width | 17-1/4" (43.9 cm) | |
| Depth (not including power cord) | 14-3/4" (37.5 cm) | |
| WEIGHT | ||
| MRX 1120 | 32 lb (14.5 kg) | |
| MRX 720 | 31 lb (14 kg) | |
| MRX 520 | 28.2 lb (12.8 kg) | |
| POWER REQUIREMENT | ||
| 120 V version: | In countries where the line voltage is 120 V, this product operates from a single phase AC power source that supplies between 108 V and 132 V at a frequency of 60 Hz. | |
| 220-240 V version: | In countries where the line voltage is 220, 230, or 240 V, this product operates from a single phase AC power source that supplies between 198 V and 264 V at a frequency of 50 Hz. | |
